ZYXEL Switch 16x1000Mbps(16xPOE) Fémházas Rackes Unmanaged DIP Selector, GS1100-16EPS-EU0101F

Description

Product name

16-port GbE PoE Unmanaged Slim Switch

Switch class

Unmanaged

Port Density

Total port count

16

10M/100M/1G (RJ-45)

16

PoE

PoE ports

16

Total PoE budget (watts)

135

IEEE 802.3at (PoE+)

Port 1~Port 16

Performance

Switching capacity (Gbps)

32

Forwarding rate (Mpps)

23.8

Packet buffer (byte)

1M

MAC address table

16K

Jumbo frame (byte)

12KB

Flash/RAM

2MB/256KB

Power

Input

100 - 240 V AC, 50/60 Hz

Min. power consumption (watts)
Without any port connection

4.15

Max. power consumption (watts)
All ports full load without PoE

10.34

Max. power consumption (watts)
All ports full load with PoE

157.9

Physical Specifications

Item

Dimensions (WxDxH)(mm/in.)
286 x 118 x 26/11.26 x 4.65 x 1.02

Weight (kg/lb.)
0.81/1.79

Included accessories

• Power cord
• Power adapter
• Wall mount kit

ESD/Surge Protections

Energy-Efficient Ethernet

2KV

Power supply surge protection

Line-GND: 4KV

Line-Line: 2KV

ESD protection (air/contact)

8KV/4KV

Environmental Specifications

Operating

Temperature
0°C to 40°C/32°F to 104°F

Humidity
10% to 95% (non-condensing)

Storage

Temperature
-40°C to 70°C/-40°F to 158°F

Humidity
10% to 95% (non-condensing)

MTBF (hr @ 25°C)

1,217,669

Heat dissipation (BTU/hr)

78.138

Acoustic noise @ 25°C (min/max, dBA)

Fanless, 0
