UBiQUiTi Switch 12x1000Mbps (POE+) + 4x2500Mbps (POE++) + 2x10Gbps SFP+, Menedzselhető, Asztali - USW-PRO-MAX-16-POE
Cikkszám:
CH-352321
UBiQUiTi Switch 12x1000Mbps (POE+) + 4x2500Mbps (POE++) + 2x10Gbps SFP+, Menedzselhető, Asztali - USW-PRO-MAX-16-POE
Nincs raktáron
Ár: 218 599 Ft (172 125 Ft+ÁFA)
Hasonló termékek
Részletek
Technical Specifications
| Mechanical | |
|---|---|
| Dimensions | 325.1 x 160 x 43.7 mm (12.8 x 6.3 x 1.7") |
| Weight | 2.1 kg (4.6 lb) |
| Enclosure material | SGCC steel |
| Hardware | |
| Management interface | Ethernet In-Band |
| Networking interface | (12) GbE RJ45 ports (4) 1/2.5 GbE RJ45 ports (2) 10G SFP+ ports |
| PoE interface | (12) PoE/PoE+ (Pins 1, 2+; 3, 6-) (4) 60W PoE++ (Pair A 1, 2+; 3, 6-) (Pair B 4, 5+; 7, 8-) |
| Total non-blocking throughput | 42 Gbps |
| Switching capacity | 84 Gbps |
| Forwarding rate | 62.496 Mpps |
| Power method | DC adapter |
| Power supply | 54V, 210W |
| Max. power consumption | 30W (Excluding PoE output) |
| Total available PoE | 180W |
| Max. PoE wattage per port by PSE | PoE: 15.4W PoE+: 30W PoE++: 60W |
| Voltage range PoE mode | PoE: 44—57V PoE+/PoE++: 50—57V |
| LCM display | (1) 1.3" touchscreen |
| Button | Factory reset |
| Ambient operating temperature | -5 to 40° C (23 to 104° F) |
| Ambient operating humidity | 10 to 90% noncondensing |
| Certifications | CE, FCC, IC |
| Switching Features | |
| Layer 2 features | IGMP snooping STP / RSTP with priorities and port-level disable Port isolation Storm control Voice VLAN Port mirroring LACP port aggregation Multicast / broadcast rate limiting MAC address blocking Flow control 802.1X control Jumbo frames Proprietary loop protection DHCP snooping / guarding Egress rate limit LLDP-MED Port restricted by MAC Device isolation with ACLs |
| Layer 3 features | DHCP for locally-managed networks DHCP relay Inter-VLAN routing between networks on same switch Static routing between local networks Network isolation with ACLs |
| Etherlighting™ | |
| Ethernet | Locating Speed/link Native VLAN/network |
| SFP+ | Locating Speed/link Native VLAN/network |
| Application Requirements | |
| UniFi Network | Version 8.1.127 and later |
Adatok
Portok száma:
16
Menedzselhetőség:
Web
Menedzselhető:
Van
SFP port:
2
Listaár:
174 879 HUF
Garancia:
24 hónap
EAN:
810084694572
Gyártói cikkszám:
USW-PRO-MAX-16-POE
Rack-be szerelhető:
Nincs
EAN:
810084694572
Garancia (hónap):
24
Termék gyártója:
UBIQUITI
PoE (Power over Ethernet):
Van
Tömeg:
3,59 kg/db
