MERCUSYS Switch 8x100Mbps(8xPOE+) + 2xLAN(1000Mbps), Fémházas Asztali/Rackes, MS110CMP
- Standards and Protocols
-
IEEE 802.3x Flow Control
- PoE Ports
-
RJ45
Standard: Compliant with 802.3 af/at Powered Devices
PoE Ports: Port 1- Port 8
PoE Power Budget: 115 W - Dimensions
-
6.7 × 3.9 × 1.1 in (171 × 98 × 27 mm)
- Interfaces
-
8× 10/100 Mbps Ports + 2× Gigabit Ports, Auto-Negotiation, Auto MDI/MDIX
- External Power Supply
-
External Power Adapter (Output: 54V/2.2A)
- Installation
-
Desktop / Wall Mount
- Data Rates
-
10/100 Mbps at Half Duplex
20/200 Mbps at Full Duplex - Jumbo Frame
-
2 KB
- Switching Capacity
-
5.6 Gbps
- MAC Address Table
-
2K
- Max Power Consumption
-
3.79W(220 V / 50 Hz, no PD connected)
130.49W(220 V / 50 Hz, with 115W PD connected
- Max Heat Dissipation
-
12.92 BTH/h (no PD connected)
444.97 BTH/h(with 115W PD connected)
- Others
- Package Contents
-
• 10-Port 10/100Mbps Desktop Switch with 8-Port PoE+ (MS110CMP)
• Power Adapter
• Quick Installation Guide - Environment
-
Operating Temperature: -10?~40? (14?~104?)
Storage Temperature: -40?~70? (-40?~158?)
Operating Humidity: 10%~90% RH non-condensing
Storage Humidity: 5%~95% RH non-condensing - Hardware
