MERCUSYS 4G/5G Modem + Wireless Router AX3000 1xWAN/LAN(1000Mbps) +1xLAN(1000Mpbs), MB521-5G
| Cellular Standards |
5G: 4.67/1.25Gbps DL/UL LTE: 1.6Gbps/211Mbps DL/UL |
|---|---|
| Cellular Bands |
5G:n1/n3/n5/n7/n8/n20/n28/n38/n40/n41/n75/n76/n77/n78 LTE-FDD:B1/B3/B5/B7/B8/B20/B28/B32 LTE-TDD:B38/B40/B41/B42/B43 DC-HSDPA/HSPA+/ HSPA/WCDMA:B1/B5/B8 |
| SIM |
1× Nano SIM Card Slot |
| Wi-Fi Class | AX3000 |
|---|---|
| Wi-Fi (2.4 GHz) | 574 Mbps |
| Wi-Fi (5 GHz) | 2402 Mbps |
| Wireless Standards | IEEE 802.11ax/ac/a/b/g/n |
| Max Channel Width | 160 MHz |
| Reception Sensitivity |
5 GHz: 11ax HE20: -64 dBm 11ax HE40: -61 dBm 11ax HE80: -59 dBm 11ax HE160: -56 dBm 11ac VHT20: -70 dBm 11ac VHT40: -67 dBm 11ac VHT80: -64 dBm 2.4 GHz: 11ax HE20: -65 dBm 11ax HE40: -62 dBm 11ac VHT20: -77 dBm 11ac VHT40: -74 dBm |
| MAX Capacity | 256 |
| Recommended Clients Limit | 128 |
| Wireless Security |
WPA-PSK / WPA2-PSK / WPA3-SAE/WPA2-Enterprise |
| Wireless Functions | Smart connect WPS Wireless Schedule Wireless Clients Statistics Easymesh Multi-SSID |
| Dimensions | 190 × 130 × 69.7 mm (7.5 × 5.1 × 2.7 in) |
|---|---|
| Interfaces |
1× GE LAN/WAN Port 1× GE LAN Port 2× 5G/4G External Antenna Ports 1× Nano SIM Card Slot |
| Antenna | Internal |
| Button |
WPS, Reset Button |
| Installation | Desktop |
| LED |
1× POWER 1× Internet 3× Signal |
| Retail Package Dimension | 250 × 240 × 89 |
| Units per Carton | 12 |
| Carton Dimension | 540 × 510 × 250 |
| Power |
12V/2A |
| Operation Mode | 5G/4G/3G Router Wireless Router |
|---|---|
| Cellular Mode | 5G Preferred 5G Only 4G Preferred 4G Only 3G Only |
| Cellular APN |
Data Roaming Network Search Band Search Profile Create APN Settings ISP File Upgrade PIN Management |
| WAN Mode |
Dynamic IP Static IP PPPoE PPTP L2TP Bridge |
| NAT Forwarding | ALG Virtual Server Port Triggering UPnP DMZ |
| Protocols | IPv4 IPv6 |
| IPTV |
√ |
| Guest Network | 2.4 GHz Guest Network 5 GHz Guest Network |
| Data Settings | Data Statistics Data Limit |
| Parental Controls | Time Control Website Filtering |
| Data Settings |
Data Statistics Data Limit |
| DHCP | Server DHCP Client List Address Reservation |
| DDNS |
DynDns NO-IP Mercusys Custom |
| VPN Client |
Open VPN PPTP VPN WireGuard VPN |
| VPN Server |
Open VPN PPTP VPN IPSec VPN WireGuard VPN |
| SMS | Inbox New Message Outbox Drafts |
| QoS | √ |
| Easymesh | √ |
| Security | IPv4 SPI Firewal Service Filtering Access Control IP & MAC Binding IPv6 Firewall |
| Kill Switch |
√ |
| ISP Feature | TR-069 |
| System |
Time Settings LED Control Diagnostics Firmware Upgrade Backup&Restore Reboot Schedule Administration System Log Traffic Statistics |
| Diagnostics |
Internet connection test Ping & Traceroute & Nslookup |
| LED Management | LED Control Night Mode |
| Device Management | MERCUSYS APP Web GUI |
| Cloud | Firmware Upgrade over the Cloud Remote Management |
| Language |
Czech Danish English Spanish French Italian Polish Romanian Russian Turkish Hungarian Indonesian Chinese - Taiwan |
| Certifications | CE |
|---|---|
| Network Services Enabled by Default |
Web Server Manage and configure device through web (HTTP/HTTPS) • Port: 80/443 Protocol: TCP DHCP Server IP address assignment (DHCP) • Port: 67 Protocol: UDP DNS DNS • Port: 53 Protocol: TCP/UDP App management Manage and configure device through app • Port: 22 Protocol: TCP • Port: 20002 Protocol:TCP/UDP UPnP Plug and Play • Port: 1900 Protocol: TCP/UDP |
| Package Contents |
5G AX3000 Wireless Dual Band Router (MB521-5G) Power Adapter RJ45 Ethernet Cable Quick Installation Guide |
| Environment | Operating Temperature: 0 °C~40 °C (32 °F~104 °F) Storage Temperature: -40 °C~60 °C (-40 °F~140 °F) Operating Humidity: 10%~90% Non-Condensing Storage Humidity: 5%~90% Non-Condensing |
